MAX3232ECAE+T

Product Summary

The MAX3232ECAE+T +3.0V-powered EIA/TIA-232 and V.28/V.24 communications interface devices features low power consumption, high data-rate capabilities, and enhanced electrostatic-discharge (ESD) protection. The enhanced ESD structure protects all transmitter outputs and receiver inputs to ±15kV using IEC 1000-4-2 Air-Gap Discharge, ±8kV using IEC 1000-4-2 Contact Discharge (±9kV for MAX3246E), and ±15kV using the Human Body Model. The MAX3232ECAE+T is available in space-saving SO, SSOP, TQFN and TSSOP packages.

Parametrics

Absolute maximum ratings: (1)VCC to GND: -0.3V to +6V; (2)V+ to GND (Note 1): -0.3V to +7V; (3)V- to GND (Note 1): +0.3V to -7V; (4)V+ + |V-| (Note 1): +13V; (5)Input Voltages: T_IN, EN, SHDN, MBAUD to GND: -0.3V to +6V; R_IN to GND: ±25V; (6)Output Voltages, T_OUT to GND: ±13.2V; R_OUT, R_OUTB (MAX3241E): -0.3V to (VCC + 0.3V); (7)Short-Circuit Duration, T_OUT to GND: Continuous; (8)Continuous Power Dissipation (TA = +70℃); (9)16-Pin SSOP (derate 7.14mW/℃ above +70℃): 571mW; (10)16-Pin TSSOP (derate 9.4mW/℃ above +70℃): 754.7mW; (11)16-Pin TQFN (derate 20.8mW/℃ above +70℃): 1666.7mW; (12)16-Pin Wide SO (derate 9.52mW/℃ above +70℃): 762mW; (13)18-Pin Wide SO (derate 9.52mW/℃ above +70℃): 762mW; (14)18-Pin PDIP (derate 11.11mW/℃ above +70℃): 889mW; (15)20-Pin TQFN (derate 21.3mW/℃ above +70℃): 1702mW; (16)20-Pin TSSOP (derate 10.9mW/℃ above +70℃): 879mW; (17)20-Pin SSOP (derate 8.00mW/℃ above +70℃) : 640mW; (18)28-Pin SSOP (derate 9.52mW/℃ above +70℃): 762mW; (19)28-Pin Wide SO (derate 12.50mW/℃ above +70℃): 1W; (20)28-Pin TSSOP (derate 12.8mW/℃ above +70℃): 1026mW; (21)32-Lead Thin QFN (derate 33.3mW/℃ above +70℃): 2666mW; (22)6 x 6 UCSP (derate 12.6mW/℃ above +70℃): 1010mW; (23)Operating Temperature Ranges: MAX32_ _EC_ _ : 0℃ to +70℃; MAX32_ _EE_ _: -40℃ to +85℃; (24)Storage Temperature Range: -65℃ to +150℃; (25)Lead Temperature (soldering, 10s): +300℃; (26)Bump Reflow Temperature (Note 2): Infrared, 15s: +200℃; Vapor Phase, 20s: +215℃.

Features

Next-generation device features: (1)MAX3228E/MAX3229E: ±15kV ESD-Protected, +2.5V to +5.5V, RS-232 Transceivers in UCSP; (2)MAX3380E/MAX3381E: +2.35V to +5.5V, 1μA, 2Tx/2Rx, RS-232 Transceivers with ±15kV ESD-Protected I/O and Logic Pins.

Diagrams
